Description

Technical Parameters of Mine Box

Box weight: approximately 2.0 tons

Color: white

External Dimensions： 5700*2200*2200mm L*W*H）

Internal Dimensions：   5500*2000*2000mm（L*W*H）

Rated power consumption: 3250W (-5%–+5%) X168 units

Miner capacity: 168 units for S19 series miners, compatible with Avalon A841, 1246, 15, 11, 9 series miners (factory default is optimized for S19 series miners)

Certification: The MMBOX168 is CSA FCL certified as a whole unit, and major components such as power distribution cabinets, PDUs, cables, and wires are UL certified.

Assembly height: Recommended not to exceed 2 layers

Assembly length: No specific requirements, determined based on the specific site.

Layout: Inlet relative to the air inlet. Recommended spacing: 9 meters, with the transformer located on the side of the air inlet. Outlet relative to the air inlet. Recommended spacing: 6 meters, with the transformer located on the side of the air inlet. The spacing between each row of containers and each group: 2.5 meters (these dimensions are recommended).
