Description
OUTPUT 1:
| Subtitle | Value |
|---|---|
| VDC Voltage | 12V-15V |
| Rated Current (230V input) | 350A |
| Ripple & Noise | <1% |
| Source Regulation | <1% |
| Load Regulation | <1% |
| Setup & Rise Time | <4S |
| Power off Protection Trip Time | >10mS |
OUTPUT 2:
| Subtitle | Value |
|---|---|
| DC Voltage | |
| Rated Current (220V input) | 15A |
| Voltage Accuracy | 12.2V-12.4V |
| Source Regulation | <1% |
| Load Regulation | <1% |
| Setup & Rise Time | <2S |
| Power off Protection Trip Time | >10mS |
AC INPUT:
| Subtitle | Value |
|---|---|
| Input Voltage, VAC | |
| Frequency Range | |
| Power Factor (Full Load) | >0.99 |
| Leakage Current (230V 50Hz) | 35A |
PROTECTIONS:
| Subtitle | Value |
|---|---|
| Under Voltage Protection (UVP) | 80-89VAC |
| Short Circuit Protection (SCP) | Yes |
| Over Temperature Protection (OTP) | Yes |
| Over Current Protection (OCP) | 366A-466A (Different voltage, different protection value) |
OPERATIONAL ENVIRONMENT:
| Subtitle | Value |
|---|---|
| Operational Temperature Range | -20°C to 45°C |
| Operation Humidity (Non-condensing) | 20%-90% |
| Altitude | 2000 meters |
DIMENSIONS:
| Subtitle | Value |
|---|---|
| Size (mm) | 254.6251.663 |
| Net Weight (Kilos) | 3.6KG |
