Description
S19 XP specifications, computing power consumption, power supply, usage environment and other related information are shown in the tables:
Product Glance |
Value |
| Version | S19 XP |
| Model | 240-Ca |
| Crypto Algorithm/Coins | SHA256/BTC/BCH |
| Hashrate, TH/s | 141 ± 3% |
| Power on Wall@25℃, Watt | 3031.5 ± 5% |
| Power Efficiency on Wall@25°C, J/TH | 21.5 ± 5% |
Detailed Characteristics |
Value |
| Power Supply | |
| Power Supply AC Input Voltage, Volt(1-1) | 200~240 |
| Power Supply AC Input Frequency Range,Hz | 47~63 |
| Power Supply AC Input Current, Amp(1-2) | 20(1-3) |
| Hardware Configuration | |
| Network Connection Mode | RJ45 Ethernet 10/100M |
| Miner Size (Length*Width*Height, w/o
package), mm(2-1) |
400*195.5*290 |
| Miner Size (Length*Width*Height, with package), mm | 570*316*430 |
| Net Weight, kg(2-2) | 14.2 |
| Gross Weight, kg | 16 |
| Environment Requirements | |
| Operation Temperature, °C | 0~40 |
| Storage Temperature, °C | -20~70 |
| Operation Humidity(non-condensing), RH | 10~90% |
| Operation Altitude, m(3-1) | ≤2000 |
*Notes:
(1-1) Caution: Wrong input voltage may probably cause miner damaged
(1-2) Max condition: temperature40°C, altitude 0m
(1-3) Two AC input wires, 10A per wire
(2-1) Including PSU size
(2-2) Including PSU weight
(3-1) When the miner is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃for every increase of 300m
